D882 NPN SILICON TRANSISTOR

SKU: ES1280

Electro Store Shopping Event

Hurry and get discounts on all Hardware Products up to 20%

ELECTRO20

Original price was: ₹15.00.Current price is: ₹7.60.

(Exclusive GST) Shipping calculated at checkout

20 People watching this product now!

Payment Methods:

Description

2SD882 is a general-purpose transistor and it is a quite high performance device, according to its features, this transistor is ideal to use in a wide variety of educational, commercial, and hobbyist electronic projects. D882 can be used for a wide variety of switching and amplification purposes. It is packed with some very interesting features, the max collector current is 3A which is enough to drive many relays, LEDs, Bulbs, motors, some part of an electronic circuit, etc. the minimum collector saturation voltage is only 0.3V.

  • Transistor Type: NPN
  • Max Collector Current(IC): 3A
  • Max Collector-Emitter Voltage (VCE): 30V
  • Max Collector-Base Voltage (VCB): 40V
  • Max Emitter-Base Voltage (VEBO): 5V
  • Max Collector Dissipation (Pc): 10 Watts
  • Max Transition Frequency (fT): 90 MHz
  • Minimum & Maximum DC Current Gain (hFE): 60 – 400
  • Max Storage & Operating temperature Should Be: -55 to +150 Centigrade
