Name: 9W 220VAC YELLOW DOB LED - Electro store
SKU: ES1550
Price: 11.00 INR
Availability: InStock

9W 220VAC YELLOW DOB LED

Exclusive GST, Shipping calculated at checkout.

This is a 220V 9W DOB LED PCB. It operates on 220V AC. It has two IC, MB10S and FM3081S8HS. And it has a total of 20 LEDs, and the colour of the LED is Blue. This PCB is mainly used in bulbs. MB10S is a bridge rectifier as a bridge rectifier is used to rectify the AC signal, which means it’s used to convert AC to DC voltage directly. This IC is used for the single-phase power supply. And it has an eight-pin IC FM3081S8HS, a single-channel LED linear constant current drive control chip. An external resistor adjusts the output current.

Applications:

Its mainly used in decorative products
It’s used in home decor LEDs
It’s used in traffic LED
Headlight
Street lights

Features:

Direct AC Source
It has a total of 20 LED
It does not need any external driver circuit
It has an inbuilt driver IC

SPECIFICATIONS:

Model	TD5649A
Type	DOB LED PCB
Input Voltage	220VAC
No of LEDs	20
Colour	Yellow
LED Diameter	38mm
Power	9W
Wire Mounting Diameter (Small hole)	2.5mm
Mounting Diameter of (large Hole)	5mm
Thickness	2.1mm
Connection Point	Line and Neutral
No. of Connecting Point	02
Country of Origin	China

Weight

0.003 kg

Dimensions

3 × 3 × 0.5 cm
